Products > Electric ball Valve > Motorized Ball Valve > Discount Flow Control Electric Linear Actuator Proportional Ball Valve for Water 12v 24v
Product name : Discount Flow Control Electric Linear Actuator Proportional Ball Valve for Water 12v 24v
Product No. : CTF-001-4-20mA-DN32-STAINLESS STEEL-DC12V/24V
valve size :
←[Previous Product]              [Next Product]→
Online Inquiry         Email Us

  Details:
 Discount Flow Control Electric Linear Actuator Proportional Ball Valve for Water 12v 24v

1. Simple design, compact size, 4-20ma adjustment, is the intermediate product

        connecting civil and industrial valves.

    2. The product running state LCD screen is visible and has manual and electric control

        functions.

    3. Adopt all-metal gear transmission, with reliable performance output torque, up to

        10NM.

    4. Adopt double limit of electrical and mechanical, accurate positioning and high

        consistency.

    5. The connection between the actuator and the valve body is ISO5211 standard, and

        the flange type is F03 and F05, which is convenient for the user to match the valve

        body.

    6. The ball valve adopts the floating seal structure, no drop leakage, which is suitable

        for heavy dirt and long period of no action.

    7. Good sealing performance, the protection grade is IP65.

Discount Flow Control Electric Linear Actuator Proportional Ball Valve for Water 12v 24v



    1. University LABS, automotive laboratories.

    2. Drug production, diesel fuel saving, etc.

    3. Small equipment such as water saving, automatic control system and industrial

        automatic control in colleges and universities;

    4. Agricultural irrigation, environmental protection, water supply and drainage, water

        treatment works;

    5. Water-saving appliances, drinking water equipment, etc.
Discount Flow Control Electric Linear Actuator Proportional Ball Valve for Water 12v 24v

Product model  Rated voltage  Working current  Output torque  Open/close time  Control mode
 CTF001 Modulating type  DC12V
DC24V
 <200mA  Max6NM  <30s  4-20mA
 Working pressure  Power  Medium temperature  Size  IP Garde  Mode of regulation
 Max1.6Mpa  <5W  0-90℃  DN8-32  IP65  Manual and electri
Discount Flow Control Electric Linear Actuator Proportional Ball Valve for Water 12v 24v
Discount Flow Control Electric Linear Actuator Proportional Ball Valve for Water 12v 24v
